What is stainless steel 321 sheet?

The austenitic stainless steel family includes 321 stainless steel sheet. 321 is essentially a 304 grade with a titanium stabiliser added. Type 321 is an excellent choice for applications where heat is a concern.

What is the difference between 321 and 316 stainless steel Sheets?

321 and 316 are two different types of stainless steel sheets. 321 is a type of stainless steel with a low carbon content while 316 is the most common type of stainless steel used in the industry.

Stainless Steel 321 Sheet/Plates Stockist, Supplier in Mumbai, India

Stainless Steel 321 Sheets/Plates include a titanium addition which is at least five times the carbon content. This titanium addition helps prevent carbide precipitation during the welding process. The UNS S32100 Sheets are not sensitive to intergranular corrosion after heating within the carbide precipitation range of 425-850 °C. SS 321 Plates have high strength and resistance to scaling and phase stability. These plates are known to have good resistance to subsequent aqueous corrosion. SS Grade 321 sheets do not polish well, so they are not recommended for decorative applications. SS 321 plate is also advantageous for high-temperature service because of its good mechanical properties. SS 321 plate offers higher creep and stress rupture properties than SS 304 Grade alloy. The alloy can be used in most diluted organic acids at moderate temperatures and in pure phosphoric acid at lower temperatures and up to 10% diluted solutions at elevated temperatures. UNS S32100 Sheets resist polythionic acid stress corrosion cracking in hydrocarbon service. It can also be utilized in chloride or fluoride-free caustic solutions at moderate temperatures.

Applications of SS 321 sheets include producing of Aircraft exhaust manifolds and Expansion Joints. Due to great heat resisting property of UNS S32100 plates, they are used in making heating element tubing, Heat Exchangers and Thermal oxidizers. We at Nexus Stainless LLP offer different types of SS 321 sheets like Coils, Foils, Rolls, Plain Sheets, Shim Sheets, etc. and different types of Plates such as Perforated Sheets, Checkered Plates, etc.

Grade	UNS	DIN	JIS	EN
SS 321	S32100	1.4541	SUS 321	X6CrNiTi18-10

Grade

UNS

DIN

JIS

SS 321

S32100

1.4541

SUS 321

X6CrNiTi18-10

Grade	C	Mn	Si	P	S	Cr	N	Ni	Ti
SS 321	0.08 max	2.0 max	1.0 max	0.045 max	0.030 max	17.00 - 19.00	0.10 max	9.00 - 12.00	5(C+N) – 0.70 max

Grade

SS 321

0.08 max

2.0 max

1.0 max

0.045 max

0.030 max

17.00 - 19.00

0.10 max

9.00 - 12.00

5(C+N) – 0.70 max

Density	Melting Point	Tensile Strength	Yield Strength (0.2%Offset)	Elongation
8.0 g/cm3	1457 °C (2650 °F)	Psi – 75000 , MPa – 515	Psi – 30000 , MPa – 205	35 %

	Thickness (mm)
0.3	0.4	0.5	0.6	0.7	0.8	0.9	1.0	1.2	1.5	2.0	3.0
Grade	Dimension (mm)	Weight (kg/sheet)
321	1000 x 2000	4.76	6.34	7.93	9.52	11.1	12.7	14.3	15.9	19.0	23.8	31.7	47.6
1219 x 2438 (4’ x 8’)	7.07	9.43	11.8	14.1	16.5	18.9	21.2	23.6	28.3	35.4	47.1	70.7
1250 x 2500	7.43	9.91	12.4	14.9	17.3	19.8	22.3	24.8	29.7	37.2	49.6	74.3
1524 x 3048 (5’ x 10’)	11.1	14.7	18.4	22.1	25.8	29.5	33.2	36.8	44.2	55.3	73.3	110.5
430	1000 x 2000	4.62	6.16	7.70	9.24	10.8	12.3	13.9	15.4	18.5	23.1	30.8	46.2
1219 x 2438 (4’ x 8’)	6.87	9.15	11.4	13.7	16.0	18.3	20.6	22.9	27.5	34.3	45.8	68.7
1250 x 2500	7.22	9.63	12.0	14.4	16.8	19.3	21.7	24.1	28.9	36.1	48.1	72.2

Thickness (mm)

0.3

0.4

0.5

0.6

0.7

0.8

0.9

1.0

1.2

1.5

2.0

3.0

Grade

Dimension (mm)

Weight (kg/sheet)

321

1000 x 2000

4.76

6.34

7.93

9.52

11.1

12.7

14.3

15.9

19.0

23.8

31.7

47.6

1219 x 2438 (4’ x 8’)

7.07

9.43

11.8

14.1

16.5

18.9

21.2

23.6

28.3

35.4

47.1

70.7

1250 x 2500

7.43

9.91

12.4

14.9

17.3

19.8

22.3

24.8

29.7

37.2

49.6

74.3

1524 x 3048 (5’ x 10’)

11.1

14.7

18.4

22.1

25.8

29.5

33.2

36.8

44.2

55.3

73.3

110.5

430

1000 x 2000

4.62

6.16

7.70

9.24

10.8

12.3

13.9

15.4

18.5

23.1

30.8

46.2

1219 x 2438 (4’ x 8’)

6.87

9.15

11.4

13.7

16.0

18.3

20.6

22.9

27.5

34.3

45.8

68.7

1250 x 2500

7.22

9.63

12.0

14.4

16.8

19.3

21.7

24.1

28.9

36.1

48.1

72.2

Grade	Density (kg/m3)	Elastic Modulus (GPa)	Mean Coefficient of Thermal Expansion(μm/m/°C)			Thermal Conductivity(W/m.K)		Specific Heat 0-100°C (J/kg.K)	Electrical Resistivity (nΩ.m)
			0-100°C	0-315°C	0-538°C	at 100°C	at 500°C
321	8027	193	16.6	17.2	18.6	16.1	22.2	500	720
