Stainless Steel 409L Sheets / Plates Stockist, Supplier

SS 409L Sheets, Stainless Steel Gr 409L Plates, 409L SS Cold Rolled Plates, Stainless Steel 409L HR Sheets, Stainless Steel 409L Jindal Sheets, 409L Stainless Steel Sheets Manufacturers, SS TP409L Sheets and Plates Stockist, SS SUS 409L Sheets & Plates, 409L Stainless Steel Sheets Suppliers, SS UNS S40903 Sheets, DIN 1.4512 Plates, Stainless Steel Grade 409L Sheets Supplier in Mumbai, India.

With the ever-increasing demand for Stainless steel, we at Nexus Stainless LLP are engaged in offering an extensive range of Stainless Steel 409L Sheets and Plates. Made with the best quality of alloys, the SS UNS S40903 plates that we offer are made sure to be solid and destructive safe material. We carry a full line of SS 409L Sheets and Plates that are at par with the National and Global standards. Longer service life helps the SS UNS S40903 sheets to be in demand among our customers. UNS S40903 sheets are made with a good combination of heat and corrosion resistivity. The SS 409L plates come in different sizes and thicknesses for use in varied industries. We also make these plates in custom dimensions as per customer’s requirements.

Stainless 409L sheet is an excellent choice for non- or weakly corrosive conditions or applications because of its good heat resistance and corrosion resistance. It can be utilised for oil equipment or vehicle exhaust pipes because of its exceptional oxidation resistance under high temperatures.
At high temperatures, this stainless steel 409L sheet offers excellent resistance against environmental corrosion and exhaust gas damage. The automobile and agricultural industries greatly benefit from these mechanical qualities.

SS 409L #8 Finish Plates, Stainless Steel 409L Jindal Make Plates, ASTM A240 TP409L Stainless Steel Sheets, ASME SA 240 SS 409L Plates, 2B Finish SS 409L Sheets, SS 409L Hot Rolled Plates, 409L Stainless Steel CR Sheets, SS Grade 409L Chequered Plates, Austenitic Stainless Steel 409L Sheets / Plates at Best Price, SS Gr 409L Industrial Sheets and Plates Exporter in India.

SS 409L sheets and plates are made using a proper composition of Chromium, Titanium and lower carbon content. The chromium content forms a passive surface film which provides higher corrosion resistivity. Atmospheric Corrosion resistance of SS 409L sheets is 250 times more than that of mild steel. The addition of titanium prevents the formation of harmful chromium carbides which can lead to intergranular corrosion in service. Titanium also helps the SS UNS S40903 plates to maintain its hard form on cooling after welding. These plates can be welded, drawn, bent folded or blanked and fabricated into a variety of shapes without any difficulty. The SS 409L grade sheets also provide great oxidation resistance and could resist up to 800 degrees. Due to its Ferritic nature, SS 409L sheets are relatively insensitive to stress corrosion cracking. With all the properties, these grade sheets are also very cost-effective and hence are suitable for a lot of applications.

Applications of SS UNS S40903 sheets particularly include the manufacturing of Automobile Exhaust Systems. They are mostly used for components that are exposed to working heat temperatures rising to 750 to 800 degrees Celsius. Manifolds, Mufflers, catalytic shells, etc use SS 409L grade sheets. Making of Heat Exchangers is one of the most demanding applications. Electric transformer cases are build using SS 409L grade sheets. These sheets are also used in the making of Farm Equipment components.

Stainless Steel 409L Sheets / Plates Equivalent Grades

Grade UNS DIN JIS EN
SS 409L S40903 1.4512 SUS 409L X2CrTi12

Standard Specification For Stainless Steel 409L Sheets and Plates

Specifications : ASTM A240 / ASME SA240

Dimensions : ASTM, ASME, and API

Width : 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc

Thickness : 4mm-100mm

Length : 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc

Surface Finish : 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, chequered, embossed, hairline, sand blast, Brush, etching, Hot rolled plate (HR), Cold rolled sheet (CR), SATIN (Met with Plastic Coated) etc

Hardness : Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc.

Form : Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc.


Chemical / Mechanical Properties

Stainless Steel 409L Plates & Sheets Chemical Composition

Grade C Mn P S Si Cr Ni
SS 409L 0.030 max 1.00 max 0.040 max 0.020 max 1.00 10.5 – 11.7 0.50

SS 409L Plates / Sheets Mechanical Properties

409L Stainless Steel Sheet Plate Stock Available

Tisco Stainless Steel 409L Sheet Plate SS 409L Perforated Sheet Plate
Stainless Steel 409L Sheet Plate ASTM A240 Stainless Steel 409L Sheet Plate
Jindal Stainless Steel 409L Sheet Plate SS DIN 1.4512 Sheet Plate
Stainless Steel 409L UNS S40903 Sheet Plate ASTM A240 Chequered Stainless Steel 409L Sheet Plate
SS 409L Embossed Sheet Plate Outokumpu SS 409L Sheet Plate
ThyssenKrupp Stainless Steel 409L Sheet Plate STM A240 Stainless Steel 409L Sheet Plate
Aperam Stainless Steel 409L Sheet Plate ASME SA240 409L Stainless Steel Sheet Plate

Available Types of 409L SS Sheets and Plates

SS 409L Sheets

Stainless Steel 409L Sheets | SS TP409L Sheets | Stainless Steel 409L HR Sheet | SUS 409L Sheets | SS TP409L Cold Rolled Sheet | 409L Stainless Steel Sheets Price | 409L SS Hot Rolled Sheets | UNS S40903 Sheets | SS DIN 1.4512 Sheets | TP409L Stainless Steel CR Sheets | 409L Stainless Steel Sheets Manufacturers | SS 409L 2D Finish Sheets | 409L Stainless Steel BA Finish Sheets | SS 409L jindal Sheets | Stainless Steel 409L Industrial Sheets | ASTM A240 SS 409L Sheets | ASME SA240 Stainless Steel 409L Sheet.

SS 409L Sheets
SS 409L Plates

SS 409L Plates

Stainless Steel 409L Plates | SS TP409L Plates | Stainless Steel 409L HR Plate | SUS 409L Plates | SS TP409L Cold Rolled Plate | 409L SS Hot Rolled Plates | UNS S40903 Plates | SS DIN 1.4512 Plates | TP409L Stainless Steel CR Plates | Stainless Steel 409L Chequered Plates | SS 409L 2D Finish Plates | SS Grade 409L Jindal Plates | 409L Stainless Steel BA Finish Plates | Stainless Steel 409L Industrial Plates | ASTM A240 SS 409L Plates | ASME SA240 Stainless Steel 409L Plate.
